Image Sensor: 1/4" COLOR CMOS(PC7070)
Imaging Area: 3.63 x 2.73(mm)
View Angle: 170°
IP Rate: IP 67
Minimum Illumination:0.2Lux
TV System: NTSC/PAL
TV Lines：480
Effective Pixels: 648H x 488V/648H x 504V
Frame Rate: 60 fields/sec(N)/ 50 fields/sec(P)
Power Consumption: 0.5W
Power Supply : DC 12V ±4V
Operating Temperature: -30°C to +85°C
Storage Temperature: –40°C to +105°C
Dimention: φ18.5x28.9mm |
|
